LMR14006XDDCR - Step-Down Voltage Regulator by Texas Instruments

The LMR14006XDDCR is a highly efficient, small form factor, step-down voltage regulator from Texas Instruments (TI), designed to deliver outstanding performance for a wide range of applications. This compact regulator is part of TI's SIMPLE SWITCHER® family, which is renowned for its ease of use and robust design. The LMR14006XDDCR is an excellent choice for designers looking for a reliable power solution that can efficiently convert a higher input voltage into a lower output voltage with minimal external components.

This voltage regulator is capable of delivering up to 0.6A of continuous output current and supports an input voltage range from 4V to 14V, making it versatile for various applications, including industrial, automotive, and consumer electronics. The output voltage is adjustable from 0.9V to 12V, which allows for great flexibility in matching the power requirements of different loads.

The LMR14006XDDCR boasts an impressive efficiency level, thanks to its current-mode control operation, which reduces switching losses and improves transient response. The device also features internal compensation, which minimizes the number of external components required and simplifies the design process. Additionally, the regulator has a fixed switching frequency of 1.4MHz, which enables the use of small surface-mount inductors and capacitors, thereby reducing the overall solution size.

For protection, the LMR14006XDDCR includes thermal shutdown, overcurrent protection, and input under-voltage lockout, ensuring the safety and reliability of your design under various conditions. The device is available in a compact 6-pin SOT-23 package, which is ideal for space-constrained applications.

Key features of the LMR14006XDDCR include:

• 0.6A Output Current Capability
• Input Voltage Range: 4V to 14V
• Adjustable Output Voltage Range: 0.9V to 12V
• High Efficiency with Current-Mode Control
• Internal Compensation
• Fixed Switching Frequency: 1.4MHz
• Thermal Shutdown and Overcurrent Protection
• Input Under-Voltage Lockout
• Compact SOT-23 Packaging

Whether you are designing power supplies for portable devices, automotive applications, or sophisticated industrial equipment, the LMR14006XDDCR offers a high-performance, space-efficient solution that is easy to implement in any project.
