LMR23610ADDA - Texas Instruments DC/DC Converter

The LMR23610ADDA from Texas Instruments is a highly efficient, small form-factor, easy-to-use, 36V, 1A synchronous step-down DC/DC converter. It is designed to deliver a reliable and constant power supply to a wide array of applications, ranging from industrial, automotive, and consumer electronics. With its advanced features and robust performance, the LMR23610ADDA is a versatile solution for your power management needs.

Key Features:

• VIN Range: The device supports a wide input voltage range from 4V to 36V, making it suitable for various power supply conditions and capable of handling high voltage surges.
• Output Current: It provides up to 1A of continuous output current, ensuring sufficient power for your applications.
• High Efficiency: With a synchronous step-down regulator design, the LMR23610ADDA achieves high efficiency, which minimizes heat generation and improves system reliability.
• Adjustable Switching Frequency: The switching frequency is adjustable from 200 kHz to 2.2 MHz, allowing designers to optimize the size of the external components and the performance of the power supply.
• Thermal Protection: The device includes thermal shutdown and overcurrent protection, safeguarding the system from thermal and current overloads.
• Small Package: Available in a small 8-pin VSSOP (DA) package, it is ideal for space-constrained applications.

Applications:

• Automotive infotainment and cluster
• Industrial power supplies
• Consumer electronics
• Telecommunications equipment

The LMR23610ADDA integrates a range of protection features, including cycle-by-cycle current limit, short-circuit protection, and thermal sensing and shutdown. Its advanced design ensures stable operation over a wide range of temperatures and load conditions. With external soft start and precision enable, the device provides flexible startup sequencing which can be tailored to your specific application requirements.

For engineers and designers looking for a reliable, high-performance DC/DC converter solution, the LMR23610ADDA from Texas Instruments offers an excellent blend of features, efficiency, and ease of use that can meet the demands of the most challenging power supply designs.
