LMV841MGX/NOPB

Part No LMV841MGX/NOPB
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 4.5MHZ RRO SC70-5
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 1
Output Type Rail-to-Rail
Slew Rate 2.5 V/μs
Gain Bandwidth Product (GBP) 4.5MHz
Current - Input Bias 0.3pA
Voltage - Input Offset 50μV
Operating Supply Current 1.03mA
Channel Output Current 37mA
Supply Voltage - Operating 2.7 V to 12 V, ±1.35 V to 6 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package SC-70-5
Win Source Part Number 142627-LMV841MGX/NOPB
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian LMV841MGX/NOPB CAD Model

Description

The LMV841MGX/NOPB is a high-quality, reliable product from Texas Instruments, a global leader in semiconductor design and manufacturing. This product is a single operational amplifier (op-amp) that is part of the company's extensive line of analog integrated circuits.

  • Supply Voltage Range: 2.7V to 5.5V (single supply)
  • Quiescent Current: 1.1mA at 5V
  • Features: Rail-to-rail output swing, input common-mode voltage range includes ground, high slew rate of 1V/µs, gain bandwidth product of 1MHz, EMI hardened design, small 5-pin SOT-23 package, RoHS and Green compliant, extended operating temperature range from -40°C to +125°C
  • Applications: Mobile phones, tablets, digital cameras, and other personal electronics

Its small footprint, combined with its excellent performance characteristics, make it a versatile choice for designers looking to optimize their systems for power, cost, and space.
