LMZ14203EXTTZ/NOPB

Part No LMZ14203EXTTZ/NOPB
Manufacturer Texas Instruments
Catalog Power Supplies Board Mount DCDC Converters
Description IC BUCK SYNC ADJ 3A TO-PMOD-7 / Module DC-DC 1-OUT 0.8V to 6V 3A 7-Pin TO-PMOD EP T/R
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Power Supplies - Board Mount
Manufacturer Texas Instruments
Series SIMPLE SWITCHER
Packaging Reel package
Type Non-Isolated PoL Module
Number of Outputs 1
Input Voltage MIN 6V
Voltage Input MAX 42V
Voltage - Output 1 0.8 ~ 6 V
Current - Output (Maximum) 3A
Applications ITE (Commercial)
Features OTP, OVP, SCP, UVLO
Operating Temperature Range -55°C ~ 125°C
Efficiency 90%
Mounting SMD
Package TO-PMOD-7, Power Module
Dimension 0.40" L x 0.39" W x 0.18" H (10.2mm x 9.9mm x 4.6mm)
Win Source Part Number 779620-LMZ14203EXTTZ/NOPB
Popularity Medium
Supply and Demand Status Limited
Family Name LMZ14203EXT
Introduction Date June 19, 2010
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LMZ14203EXTTZ/NOPB CAD Model

Description

The LMZ14203EXTTZ/NOPB from Texas Instruments is a highly efficient, versatile, and robust power module designed for a wide range of applications. This easy-to-use step-down power module integrates an advanced DC/DC converter with inductors, capacitors, and a shielded housing to provide a complete power solution. The device is capable of driving up to 3A of load current with exceptional power conversion efficiency, thermal performance, and energy management.

Key Features

  • Output Voltage Range: The LMZ14203EXTTZ/NOPB supports an adjustable output voltage range from 0.8V to 6V, which allows for a high level of versatility in different applications and design requirements.
  • Input Voltage Range: It operates over a wide input voltage range from 6V to 42V, making it suitable for a variety of input sources, including industrial supply rails and automotive batteries.
  • High Efficiency: With an integrated shielded inductor, the power module offers high efficiency and excellent EMI performance, reducing the need for external components and simplifying design.
  • Thermal Performance: The innovative package design enhances thermal performance and reliability. It is capable of operating over an extended temperature range, making it ideal for harsh environments.
  • Protection Features: The device includes built-in protection features such as over-temperature protection, under-voltage lockout, and over-current protection, ensuring safe operation under various conditions.

Applications

The LMZ14203EXTTZ/NOPB is suitable for a range of applications, including:

  • Telecommunications infrastructure
  • Industrial systems
  • Automotive applications
  • Networking equipment
  • Enterprise systems

With its robust design and comprehensive feature set, the LMZ14203EXTTZ/NOPB from Texas Instruments is an ideal choice for designers looking for a reliable and efficient power management solution. Its ease of use and integration make it a go-to component for accelerating the development cycle and improving overall system performance.
