LP2992IM5X-3.3/NOPB Real Image LP2992IM5X-3.3/NOPB Real Image
Same model may have multiple batches, images only for reference.
LP2992IM5X-3.3/NOPB Real Image LP2992IM5X-3.3/NOPB Real Image
LP2992IM5X-3.3/NOPB Real Image LP2992IM5X-3.3/NOPB Real Image
Same model may have multiple batches, images only for reference.

LP2992IM5X-3.3/NOPB

Part No LP2992IM5X-3.3/NOPB
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description IC REG LDO 3.3V 0.25A SOT23-5
Datasheet
LP2992IM5X-3.3/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Fixed
Number of Regulators 1
Maximum Input Voltage 16V
Nominal Output Voltage (Min/Fixed) 3.3V
Dropout Voltage-Max 0.85V @ 250mA
Output Current 250mA
Operating Supply Current 95μA to 4mA
PSRR 45dB (1kHz)
Control Features Enable
Protection Features Over Current, Over Temperature, Short Circuit
Temperature Range - Operating -40°C to 125°C
Regulator Topology Positive Fixed
Output Voltage 3.3V
Voltage - Dropout (Typical) 0.45V @ 250mA
Mounting SMD (SMT)
Case / Package SOT-23-5
Win Source Part Number 122625-LP2992IM5X-3.3/NOPB
Ultra Librarian 3D Model Ultra Librarian LP2992IM5X-3.3/NOPB CAD Model

Description

The LP2992IM5X-3.3/NOPB is a remarkable product from the renowned manufacturer Texas Instruments. This product is a low-dropout (LDO) regulator designed to provide superior performance in a range of applications. It is specifically designed to deliver a continuous load current of 250mA and offers an output voltage of 3.3V.

  • Output Voltage: 3.3V
  • Continuous Load Current: 250mA
  • Low Dropout Voltage: Ensures functional stability even when the input voltage is close to the output voltage
  • High PSRR: Effectively filters out noise from the power supply
  • Temperature Range: -40°C to 125°C
  • Package: SOT-23
  • Features: Low quiescent current, thermal shutdown, and short circuit protection
