LP3982IMM-ADJ/NOPB Real Image LP3982IMM-ADJ/NOPB Real Image
Same model may have multiple batches, images only for reference.
LP3982IMM-ADJ/NOPB Real Image LP3982IMM-ADJ/NOPB Real Image
LP3982IMM-ADJ/NOPB Real Image LP3982IMM-ADJ/NOPB Real Image
Same model may have multiple batches, images only for reference.

LP3982IMM-ADJ/NOPB

Part No LP3982IMM-ADJ/NOPB
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Linear
Description LDO Regulator Pos 1.25V to 6V 0.3A 8-Pin VSSOP T/R / IC REG LDO ADJ 0.3A 8VSSOP
Datasheet
LP3982IMM-ADJ/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Output Type Adjustable
Number of Regulators 1
Maximum Input Voltage 6V
Nominal Output Voltage (Min/Fixed) 1.25V
Maximum Output Voltage 6V
Dropout Voltage-Max 220mV
Output Current 300mA
Operating Supply Current 270μA
Control Features Enable
Protection Features Over Current, Over Temperature
Temperature Range - Operating -40°C to 85°C
Regulator Topology Positive Adjustable
Output Voltage 1.25 V to 6 V
Voltage - Dropout (Typical) 0.12V @ 300mA
Mounting SMD (SMT)
Case / Package 8-VSSOP
Win Source Part Number 019849-LP3982IMM-ADJ/NOPB
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Wireless, Power Management, Portable Devices
Family Name LP3982
Introduction Date April 23, 2004
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian LP3982IMM-ADJ/NOPB CAD Model

Description

The LP3982IMM-ADJ/NOPB from Texas Instruments is a high-performance, low-dropout regulator designed to meet the rigorous requirements of portable and mobile devices. This product is designed to provide a highly efficient and reliable solution for applications where voltage conversion is needed.

  • Output Current: 300mA
  • Ground Current: 190uA at full load
  • Output Voltage Range: 1.2V to 5.5V
  • Features: Adjustable output voltage, shutdown pin, over-temperature and over-current protection, output capacitor for improved stability
  • Package: Small, 8-pin VSSOP package
  • Operating Temperature: -40°C to 125°C
