OPA1642AIDR Real Image OPA1642AIDR real image4247
Same model may have multiple batches, images only for reference.
OPA1642AIDR Real Image OPA1642AIDR real image4247
OPA1642AIDR Real Image OPA1642AIDR real image4247
Same model may have multiple batches, images only for reference.

OPA1642AIDR

Part No OPA1642AIDR
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP AUDIO 11MHZ RRO 8SOIC
Datasheet
OPA1642AIDR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type Audio
Number of Circuits 2
Output Type Rail-to-Rail
Slew Rate 20 V/μs
Gain Bandwidth Product (GBP) 11MHz
Current - Input Bias 2pA
Voltage - Input Offset 1mV
Operating Supply Current 1.8mA
Channel Output Current 36mA
Supply Voltage - Operating 4.5 V to 36 V, ±2.25 V to 18 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 109192-OPA1642AIDR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name OPA1642
Introduction Date August 01, 2009
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian OPA1642AIDR CAD Model

Description

The OPA1642AIDR is a high-performance, JFET-input audio operational amplifier from the renowned technology company, Texas Instruments.

  • Supply Range: ±2.5 V to ±18 V
  • THD: 0.00005% @ 1kHz
  • SNR: 120dB
  • Slew Rate: 20V/µs
  • Open-Loop Gain: 120dB
  • Package: 8-pin SOIC
  • Operating Temperature Range: -40°C to +85°C
