OPA2228U/2K5 Real Image OPA2228U/2K5 real image
Same model may have multiple batches, images only for reference.
OPA2228U/2K5 Real Image OPA2228U/2K5 real image
OPA2228U/2K5 Real Image OPA2228U/2K5 real image
Same model may have multiple batches, images only for reference.

OPA2228U/2K5

Part No OPA2228U/2K5
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 33MHZ 8SOIC
Datasheet
OPA2228U/2K5 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 2
Slew Rate 11 V/μs
Gain Bandwidth Product (GBP) 33MHz
Current - Input Bias 2.5nA
Voltage - Input Offset 5μV
Operating Supply Current 3.7mA
Channel Output Current 45mA
Supply Voltage - Operating 5 V to 36 V, ±2.5 V to 18 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 143641-OPA2228U/2K5
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian OPA2228U/2K5 CAD Model

Description

Product OPA2228U/2K5 is a high-performing operational amplifier from Texas Instruments, a renowned global semiconductor company known for its advanced analog ICs and embedded processors.

  • Noise Level: 2.3nV/√Hz
  • Bandwidth: 33 MHz
  • Slew Rate: 20 V/μs
  • Dual Supply Voltage: ±2.5 to ±18V
  • Single Supply Voltage: 5 to 36V
  • Open-Loop Gain: 120 dB
  • Input Bias Current: 10nA
  • Total Harmonic Distortion: 0.000015%
  • Package: SOIC-8
  • Operating Temperature Range: -40°C to +85°C
