OPA2301AIDGKR Real Image OPA2301AIDGKR Real Image
Same model may have multiple batches, images only for reference.
OPA2301AIDGKR Real Image OPA2301AIDGKR Real Image
OPA2301AIDGKR Real Image OPA2301AIDGKR Real Image
Same model may have multiple batches, images only for reference.

OPA2301AIDGKR

Part No OPA2301AIDGKR
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP VFB 150MHZ 8VSSOP
Datasheet
OPA2301AIDGKR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type Voltage Feedback
Number of Circuits 2
Slew Rate 80 V/μs
Gain Bandwidth Product (GBP) 150MHz
Current - Input Bias 0.1pA
Voltage - Input Offset 1mV
Operating Supply Current 9.5mA
Channel Output Current 70mA
Supply Voltage - Operating 2.7 V to 5.5 V, ±1.35 V to 2.75 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 8-VSSOP
Win Source Part Number 090404-OPA2301AIDGKR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian OPA2301AIDGKR CAD Model

Description

The OPA2301AIDGKR is a high-performance, precision operational amplifier from Texas Instruments, a renowned global semiconductor company that designs, manufactures, tests, and sells analog and embedded processing chips.

  • Package: VSSOP
  • Key Features: Low offset voltage, low input bias current, low noise density
  • Bandwidth: 2.5MHz
  • Slew Rate: 1.3V/µs
  • Supply Voltage: Single supply
  • Protection: Built-in electrostatic discharge (ESD) protection
  • Operating Temperature Range: Wide range
