OPA698IDR Texas Instruments OPA698IDR Real Image OPA698IDR Real Image1 OPA698IDR Real Image2 OPA698IDR Real Image3
Same model may have multiple batches, images only for reference.
OPA698IDR Texas Instruments OPA698IDR Real Image OPA698IDR Real Image1 OPA698IDR Real Image2 OPA698IDR Real Image3
OPA698IDR Texas Instruments OPA698IDR Real Image OPA698IDR Real Image1 OPA698IDR Real Image2 OPA698IDR Real Image3
Same model may have multiple batches, images only for reference.

OPA698IDR

Part No OPA698IDR
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP VFB 250MHZ 8SOIC / Op Amp Single High Speed Amplifier ±6V/12V 8-Pin SOIC T/R
Datasheet
OPA698IDR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type Voltage Feedback
Number of Circuits 1
Slew Rate 1100 V/μs
Gain Bandwidth Product (GBP) 250MHz
-3db Bandwidth 450MHz
Current - Input Bias 3μA
Voltage - Input Offset 2mV
Operating Supply Current 15.5mA
Channel Output Current 120mA
Supply Voltage - Operating 5 V to 12 V, ±2.5 V to 6 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 026184-OPA698IDR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name OPA698
Introduction Date January 01, 2005
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian OPA698IDR CAD Model

Description

The OPA698IDR is a cutting-edge product from the renowned technology company, Texas Instruments.

  • Bandwidth: 2.5GHz
  • Slew Rate: 1900V/us
  • Input Voltage Noise: 4.6nV/√Hz
  • Output Clamping: Integrated output clamping feature.
  • Disable Feature: Decreases power consumption when the device is not in use.
  • Package: 8-pin package
  • Operating Temperature Range: -40°C to 85°C
  • Compliance: RoHS compliant and lead-free
