The PCI2250PGF is a high-performance, PCI-to-PCI bridge chip from the renowned semiconductor manufacturer Texas Instruments. Designed to bridge between two PCI buses, this component is an essential part of expanding the capabilities of embedded systems, servers, and a wide range of computing applications that require additional PCI slots.

Key Features

• PCI Bus Compatibility: The PCI2250PGF is compliant with PCI Local Bus Specification Revision 2.2, ensuring broad compatibility with existing PCI-based systems and devices.
• 32-Bit Interface: It features a 32-bit PCI bus interface operating at 33MHz, which allows for a balanced performance that is suitable for many industrial and commercial applications.
• Dual PCI Bus Support: As a bridge chip, it connects two independent PCI buses, effectively doubling the potential expansion capacity of a system.
• Programmable Configuration: The device offers programmable memory and I/O windows, providing flexibility for system configuration and optimization.
• Low Power Consumption: Designed with power efficiency in mind, the PCI2250PGF maintains a low power consumption profile, making it suitable for power-sensitive applications.
• Enhanced Data Integrity: It incorporates features that enhance data integrity, such as parity error detection on both the primary and secondary interfaces.

Applications

The PCI2250PGF is ideal for use in a variety of applications, including:

• Multi-function peripherals
• Network routers and switches
• Embedded computing systems
• Industrial control systems
• Data acquisition devices
• Server expansions

Quality and Reliability

Texas Instruments is known for its commitment to quality, and the PCI2250PGF is no exception. It is manufactured to the highest industry standards, ensuring reliability and performance for critical applications. With Texas Instruments' extensive support and documentation, integrating the PCI2250PGF into your system can be done with confidence.
