The SN55LBC180RSAT is a robust differential line driver and receiver pair offered by Texas Instruments, designed to operate using signaling rates up to 30 Mbps. This product is part of Texas Instruments' interface family, specifically tailored for balanced transmission lines and is compliant with the TIA/EIA-485-A standard. The device is characterized for operation over the full industrial temperature range (-40°C to 85°C).

Key Features

• High-Speed Operation: The SN55LBC180RSAT is capable of handling signaling rates as high as 30 Mbps, making it suitable for high-speed data transmission applications.
• Low Power Consumption: It is designed for low power consumption, which is essential for energy-efficient designs and applications.
• Robust Protection: The device includes protection against driver output short-circuit to battery and ground, as well as receiver input short-circuit to battery and ground, thus ensuring reliability and longevity even in harsh conditions.
• Wide Common-Mode Voltage Range: The receiver can handle a wide common-mode voltage range, which allows for flexible and reliable data communication even in the presence of ground potential differences.
• Thermal Shutdown Protection: Thermal shutdown protection is integrated to prevent damage from excessive power dissipation and over-temperature conditions.

Applications

The SN55LBC180RSAT is well-suited for a variety of applications that require balanced data transmission. These include, but are not limited to:

• Industrial control systems
• Networking equipment
• Telecommunications systems
• Factory automation
• Professional audio equipment

Package and Quality

This product is available in a compact RSAT package, which is designed to optimize board space in densely packed electronic systems. Texas Instruments maintains a strong commitment to quality and reliability, and the SN55LBC180RSAT is no exception, adhering to the stringent standards for which Texas Instruments is known.
