The SN65176BDR/SN65176B from Texas Instruments is a differential bus transceiver designed to provide bidirectional communication for balanced transmission lines. It is part of the industry-standard SN75176B family, offering improved performance with lower power consumption and increased data rates. This makes it an ideal choice for interfacing with RS-485 and RS-422 communication standards, commonly used in industrial control systems, networked devices, and telecommunication applications.

Key Features

• Bus-Pin ESD Protection: This device features an impressive electrostatic discharge (ESD) protection for bus pins, ensuring reliability and longevity in harsh environments.
• High-Speed Operation: With the capability to transfer data at rates up to 10 Mbps, the SN65176BDR/SN65176B is suitable for high-speed communication requirements.
• Low Power Consumption: The transceiver operates with a very low supply current, making it an energy-efficient solution for power-sensitive applications.
• Differential Signaling: This method of signaling allows for greater noise immunity and longer cable runs, making the device robust against electrical noise and signal degradation.
• Wide Supply Voltage Range: It supports a wide range of supply voltages from 4.5 V to 5.5 V, providing flexibility in various system designs.

Applications

• Industrial Control Networks
• Building Automation
• Telecommunications Equipment
• Networked Security Systems
• Data Acquisition Systems

Package and Quality

The SN65176BDR/SN65176B is available in an 8-pin SOIC package, offering a compact footprint for space-constrained applications. Texas Instruments ensures high manufacturing standards, providing a robust and reliable component for your electronic designs. The device also meets or exceeds the requirements of the ANSI TIA/EIA-485-A and ITU recommendations V.11 and X.27.

Environmental and Regulatory Compliance

Committed to environmental stewardship, Texas Instruments designs products that comply with global environmental regulations. The SN65176BDR/SN65176B transceiver is RoHS compliant, ensuring it meets the European Union's directives on the restriction of hazardous substances.
