SN74AHC125D

Part No SN74AHC125D
Manufacturer Texas Instruments
Catalog Logic - Buffers, Drivers, Receivers, Transceivers
Description IC BUF NON-INVERT 5.5V 14SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Estimated Pruduction Lead Time 5 Weeks
Features Buffer, Non-Inverting 4 Element 1 Bit per Element 3-State Output 14-SOIC
Manufacturer Texas Instruments
Series 74AHC
Package Tube
Operating Temperature Range -40°C ~ 125°C (TA)
Mounting Surface Mount
Package 14-SOIC (0.154", 3.90mm Width)
Case / Package 14-SOIC
Family Name 74AHC125
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Part Number 296-33669-5, -SN74AHC125DE4, SN74AHC125DE4, SN74AHC125DG4-ND, -SN74AHC125DE4-NDR, -SN74AHC125DG4, SN74AHC125DG4, SN74AHC125D-ND, SN74AHC125DE4-ND, -296-33669-5-ND, -SN74AHC125DG4-NDR
Quantity per package 50
Popularity High
Supply and Demand Status Balance
Win Source Part Number 934523-SN74AHC125D
Ultra Librarian 3D Model Ultra Librarian SN74AHC125D CAD Model

Description

The SN74AHC125D from Texas Instruments is a high-performance, quad bus buffer gate featuring 3-state outputs that are designed to drive bus lines or buffer memory address registers. This integrated circuit is part of the 'AHC' family, which is characterized by its high-speed and low-power consumption, making it suitable for a wide range of applications including mobile phones, consumer electronics, and industrial control systems.

Key Features

  • Logic Type: Quad Buffer/Line Driver with 3-State Outputs
  • Operating Voltage: 2V to 5.5V, accommodating a variety of logic levels and providing a wide range of power supply options.
  • Output Drive Capability: Capable of driving up to 8 mA at 5V, allowing for direct drive of small loads.
  • High On-Off Output Voltage Ratio: Ensures clear distinction between high and low logic levels.
  • Low Crosstalk: Minimizes signal interference, providing cleaner signal transmission.
  • Fast Propagation Delays: Ensures quick response times, making it suitable for high-speed applications.
  • Low Power Consumption: Ideal for battery-operated and power-sensitive applications.
  • Package: Available in a 14-pin SOIC package, providing a compact footprint for space-constrained applications.

Applications

The versatile SN74AHC125D is used in a variety of applications where signal buffering is required, including:

  • Memory address buffering
  • Driving bus lines
  • Data transmission systems
  • Microprocessor or microcontroller interfacing
  • Portable and battery-powered electronics

Quality and Reliability

Texas Instruments is known for its commitment to quality and reliability. The SN74AHC125D is no exception and is manufactured to the highest standards, ensuring stable and reliable performance in even the most demanding conditions.

Whether you're designing a new system or upgrading an existing one, the SN74AHC125D provides the performance and features needed for efficient and reliable digital signal buffering.
