SN74AHC14DBR

Name: SN74AHC14DBR
Brand: Texas Instruments
SKU: 331531
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SN74AHC14DBR
Manufacturer	Texas Instruments
Catalog	Logic - Gates and Inverters
Description	IC HEX SCHMITT-TRIG INV 14-SSOP
Datasheet	SN74AHC14DBR Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Texas Instruments
Packaging	Reel - TR
Status	Active
Logic Type	Inverter
Number of Circuits	6
Number of Inputs	6
Features	Schmitt Trigger
Supply Voltage - Operating	2 V to 5.5 V
Current - Quiescent (Max)	2μA
Current - Output High, Low	8mA, 8mA
Logic Level - Low	0.9 V to 1.65 V
Logic Level - High	2.2 V to 3.85 V
Max Propagation Delay @ V, Max CL	10.6ns @ 5V, 50pF
Temperature Range - Operating	-40°C to 125°C
Mounting	SMD (SMT)
Case / Package	14-SSOP
Dimension	14-SSOP (0.209", 5.30mm Width)
Win Source Part Number	115256-SN74AHC14DBR
Popularity	Medium
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian SN74AHC14DBR CAD Model

Description

The SN74AHC14DBR is a high-performance integrated circuit (IC) from Texas Instruments, a global leader in semiconductor technology.

Function: Hex Schmitt-trigger inverter
Operating Voltage Range: 2V to 5.5V
Noise Immunity: Typically 1.5V
Package: Small, surface-mount SSOP (Shrink Small-Outline Package) with 14 pins
Operating Temperature: -40°C to 85°C
Power Consumption: Low
LSTTL Input Logic Compatibility: Direct, even @ VCC = 5V
