Product Overview: SN74AHC1G04DRLR

The SN74AHC1G04DRLR is a high-speed CMOS device from Texas Instruments, designed to deliver the functionality of a single inverter gate. This integrated circuit is part of the AHC family, known for its robust performance and compatibility with a wide range of applications. The SN74AHC1G04DRLR is particularly suitable for systems that require logic-level conversions and signal inversion with a minimal footprint.

Key Features

• Logic Type: Inverter
• Number of Circuits: Single
• Supply Voltage Range: 2V to 5.5V
• Operating Temperature: -40°C to 85°C
• Output Current: ±8mA
• Propagation Delay Time: 4.5ns at 4.5V
• Mounting Type: Surface Mount
• Package / Case: SOT-5X3
• Logic Level - Low: 0.5V (Max) at 2V
• Logic Level - High: 1.5V (Min) at 2V

Applications

The SN74AHC1G04DRLR is versatile and can be used in a variety of digital applications. It is often implemented in logic circuits for:

• Signal processing
• Data manipulation
• Function generation
• Power management systems
• Consumer electronics
• Embedded systems

Performance and Quality

With its fast propagation delay and low power consumption, the SN74AHC1G04DRLR is engineered for efficient performance in high-speed digital environments. The device also features balanced drive characteristics, ensuring low noise and stable operation.

Environmental and Regulatory Compliance

The SN74AHC1G04DRLR is compliant with the RoHS directive, making it suitable for use in environmentally sensitive applications. Texas Instruments is committed to producing eco-friendly products without compromising on quality and performance.

Conclusion

As a compact and reliable solution from Texas Instruments, the SN74AHC1G04DRLR inverter is an excellent choice for designers looking to incorporate a single gate inverter into their digital systems. Its high-speed operation, low power draw, and small package size make it an ideal component for modern electronic applications requiring precision and efficiency.
