SN74AUC1G08DCKR Real Image SN74AUC1G08DCKR Real Image
Same model may have multiple batches, images only for reference.
SN74AUC1G08DCKR Real Image SN74AUC1G08DCKR Real Image
SN74AUC1G08DCKR Real Image SN74AUC1G08DCKR Real Image
Same model may have multiple batches, images only for reference.

SN74AUC1G08DCKR

Part No SN74AUC1G08DCKR
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description IC GATE AND 1CH 2-INP SC-70-5
Datasheet
SN74AUC1G08DCKR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type AND Gate
Number of Circuits 1
Number of Inputs 2
Supply Voltage - Operating 0.8 V to 2.7 V
Current - Quiescent (Max) 10μA
Current - Output High, Low 9mA, 9mA
Logic Level - Low 0.7V
Logic Level - High 1.7V
Max Propagation Delay @ V, Max CL 2ns @ 2.5V, 30pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package SC-70-5
Dimension 5-TSSOP, SC-70-5, SOT-353
Win Source Part Number 029874-SN74AUC1G08DCKR
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian SN74AUC1G08DCKR CAD Model

Description

The SN74AUC1G08DCKR is a high-quality, advanced single 2-input positive-AND gate manufactured by Texas Instruments, a leading global semiconductor company.

  • Voltage Range: 0.8 to 2.7 volts
  • Maximum tpd: 0.9 ns
  • Operation Temperature: -40°C to 85°C
  • ICC: Low ICC of 10μA
  • Output Drive: Balanced output drive
  • Logic Circuit: CMOS logic circuit
  • Configuration: Single gate design
  • Package: Small SC70 package
  • Feature: ESD protection circuit
  • Compliance: RoHS compliant
