Product Overview - SN74AUP1G02DPWR

The SN74AUP1G02DPWR is a high-performance, low-power single 2-input positive-NOR gate designed by Texas Instruments, a leader in semiconductor technology. This device is part of the advanced ultra-low power (AUP) family and operates on a very low voltage range, making it ideal for battery-operated and portable applications where power efficiency is critical.

Key Features

• Low Power Consumption: The SN74AUP1G02DPWR is optimized for ultra-low power consumption, with a typical ICC of just 0.9 µA, making it suitable for energy-sensitive designs.
• Wide Operating Voltage Range: It functions within a voltage range of 0.8 V to 3.6 V, providing design flexibility for various applications.
• High-Speed Operation: Despite its low power usage, this NOR gate does not compromise on speed, offering a typical tpd of 3.7 ns at 3.3 V, ensuring quick response times in circuits.
• ESD Protection: The device includes robust electrostatic discharge (ESD) protection, withstanding up to 2 kV on human body model (HBM).
• Small Footprint: The SN74AUP1G02DPWR comes in a small TSSOP package, making it well-suited for space-constrained applications.

Applications

The versatility of the SN74AUP1G02DPWR allows it to be used in a variety of applications, including:

• Smartphones and tablets
• Wearable technology
• Portable medical devices
• Energy management systems
• Low-power IoT devices

Quality and Reliability

Texas Instruments is renowned for its commitment to quality, and the SN74AUP1G02DPWR is no exception. It is designed to meet the stringent requirements of the industrial and consumer electronics markets, ensuring reliable performance across a wide range of environmental conditions.

Ordering Information

The product is available in a tape and reel format, with the ordering number SN74AUP1G02DPWR, to facilitate easy assembly during the manufacturing process. For detailed specifications, technical documents, and ordering options, visit the Texas Instruments official website or contact an authorized distributor.
