SN74HC14DBR Real Image SN74HC14DBR real image5978 SN74HC14DBR Real Image
Same model may have multiple batches, images only for reference.
SN74HC14DBR Real Image SN74HC14DBR real image5978 SN74HC14DBR Real Image
SN74HC14DBR Real Image SN74HC14DBR real image5978 SN74HC14DBR Real Image
Same model may have multiple batches, images only for reference.

SN74HC14DBR

Part No SN74HC14DBR
Manufacturer Texas Instruments
Catalog Logic - Gates and Inverters
Description IC INV HEX SCHMITT-TRIGG 14SSOP
Datasheet
SN74HC14DBR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Logic Type Inverter
Number of Circuits 6
Number of Inputs 6
Features Schmitt Trigger
Supply Voltage - Operating 2 V to 6 V
Current - Quiescent (Max) 2μA
Current - Output High, Low 5.2mA, 5.2mA
Logic Level - Low 0.3 V to 1.2 V
Logic Level - High 1.5 V to 4.2 V
Max Propagation Delay @ V, Max CL 21ns @ 6V, 50pF
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 14-SSOP
Dimension 14-SSOP (0.209", 5.30mm Width)
Win Source Part Number 006830-SN74HC14DBR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian SN74HC14DBR CAD Model

Description

The SN74HC14DBR is a high-performance, integrated circuit product from the globally renowned technology company, Texas Instruments.

  • Function: Hex Schmitt-Trigger Inverter
  • Voltage Range: 2V to 6V
  • Operating Temperature Range: from -40°C to 85°C
  • Package: small-outline package
  • Compliance: RoHS compliant
