Overview of SN74LVC1G74DCUT

The SN74LVC1G74DCUT is a single positive-edge-triggered D-type flip-flop designed by Texas Instruments, a leader in semiconductor solutions. This compact and efficient device is part of the LVC (Low-Voltage CMOS) family, offering a system designer a mix of speed, low power consumption, and robustness in a small package.

Key Features

• Low Voltage Operation: The SN74LVC1G74DCUT operates at a voltage range of 1.65V to 5.5V, making it versatile for various applications that require different power levels.
• High Speed: With a typical t<sub>pd of 3.4 ns at 3.3V, it provides high-speed operation, which is crucial for fast data processing and clocked applications.
• Low Power Consumption: The device is designed for low power consumption, ensuring energy efficiency in the systems where it is deployed.
• Output Drive Capability: It can drive up to 24 mA at the outputs, allowing for direct interfacing with a wide range of other components.
• Edge-Triggered Storage: The edge-triggered nature of the flip-flop ensures that data is stored securely on the rising edge of the clock signal, providing precise control over data flow.
• Multiple Configurations: The SN74LVC1G74DCUT supports clear and preset functions for added flexibility in system design.

Applications

The device is widely used across various applications due to its versatility and performance. It is ideal for:

• Frequency division
• Counters
• Control registers
• Data storage and transfer systems
• Other logic applications that require individual flip-flop operations

Package and Quality

The SN74LVC1G74DCUT comes in a small 3.5-mm × 3.5-mm VSON package, which is perfect for space-constrained applications. Texas Instruments is known for its commitment to quality, and this product is no exception. It is designed and manufactured to meet the highest standards, ensuring reliability and performance for critical applications.

In summary, the SN74LVC1G74DCUT from Texas Instruments is a versatile, high-performance D-type flip-flop that is suitable for a wide range of electronic applications. Its low power consumption, high-speed operation, and robust package make it an excellent choice for designers looking for a reliable flip-flop solution.
