Product Overview: SN74LVC1G86DCKT

The SN74LVC1G86DCKT is a high-performance, single 2-input exclusive-OR gate integrated circuit from Texas Instruments, designed for use in a wide range of digital applications. This device operates on a 1.65 to 5.5 V supply voltage range, making it suitable for interfacing with both 3.3 V and 5 V logic levels. It is part of the LVC family, which is known for its low-voltage operation and low power consumption.

Constructed with advanced silicon-gate CMOS technology, the SN74LVC1G86DCKT ensures that the quiescent power consumption is minimized when the device is in a static condition. The IC features balanced propagation delays and transition times, which contributes to its reliable and predictable performance across the entire supply voltage range.

The SN74LVC1G86DCKT comes in a compact SC70 package, which is ideal for space-constrained applications. The small footprint of this package allows for high-density mounting and is a perfect fit for portable and miniaturized electronic devices.

Key Features:

• Logic Family: LVC
• Logic Type: 2-Input Exclusive-OR Gate
• Supply Voltage Range: 1.65 V to 5.5 V
• Low Quiescent Current
• Input Voltage Level Translation from 5V to 3.3V
• High-Drive Outputs (-24 mA IOL, 24 mA IOH)
• Propagation Delay Time: 3.4 ns at 3.3 V, 2.6 ns at 5 V
• Operating Temperature Range: -40°C to 85°C
• Mounting Type: Surface Mount
• Package / Case: SC-70-6

As a versatile component, the SN74LVC1G86DCKT is designed to perform the exclusive-OR function, which is a fundamental operation in various digital circuits including parity generators and checkers, adders/subtractors, and digital comparators. Its ability to handle 5 V tolerant inputs makes it compatible with TTL logic levels, thereby providing design flexibility and ease of integration into mixed-voltage systems.

The SN74LVC1G86DCKT is RoHS compliant and supports the standard commercial temperature range, making it a reliable choice for industrial, consumer, and computing applications. Whether you're designing a new system or upgrading an existing one, the SN74LVC1G86DCKT from Texas Instruments is an excellent choice for a high-performance exclusive-OR logic function.
