SN74LVC1T45QDCKRQ1

Part No SN74LVC1T45QDCKRQ1
Manufacturer Texas Instruments
Catalog Logic - Translators, Level Shifters
Description IC BUS TXRX DUAL SC70-6
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Translator Type Voltage Level
Channel Type Bidirectional
Number of Circuits 1
Channels per Circuit 1
Voltage - VCCA 1.65V to 5.5V
Voltage - VCCB 1.65V to 5.5V
Output Type Tri-State, Non-Inverted
Data Rate 420Mbps
Temperature Range - Operating -40°C to 125°C (TA)
Mounting SMD (SMT)
Case / Package SC-70-6
Win Source Part Number 1100537-SN74LVC1T45QDCKRQ1
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian SN74LVC1T45QDCKRQ1 CAD Model

Description

SN74LVC1T45QDCKRQ1 - Texas Instruments

The SN74LVC1T45QDCKRQ1 is a versatile single-bit dual-supply bus transceiver from Texas Instruments, designed with the automotive industry in mind. This high-quality integrated circuit is part of TI's extensive range of logic-level translation solutions, catering to the needs of modern vehicles and advanced electronic systems that require reliable and efficient voltage level translation.

Key Features:

  • Flexible Power Supply: The device supports a dual-supply voltage operation, ranging from 1.65V to 5.5V on both the A and B ports. This allows for seamless communication between devices operating at different voltage levels, making it ideal for multi-voltage systems.
  • Automotive Grade: As a Q1 automotive-grade product, it meets stringent quality and reliability standards, including extended temperature ranges and robustness for harsh environments.
  • Direction Control: The SN74LVC1T45QDCKRQ1 features direction control (DIR) input, which allows for bidirectional data flow between the A and B ports. This adds to the flexibility and ease of use in complex automotive applications.
  • Low Power Consumption: With its low-power design, the device ensures minimal power draw, which is critical in automotive applications where power efficiency is a priority.
  • High-Speed Data Transfer: It is capable of facilitating high-speed data transfer, ensuring that communication between components is both rapid and reliable.
  • ESD Protection: The device includes robust electrostatic discharge (ESD) protection, safeguarding the transceiver against static electricity and other transient voltage spikes.

Applications:

The SN74LVC1T45QDCKRQ1 is suitable for a broad range of applications within the automotive sector, including but not limited to:

  • Infotainment Systems
  • Body Control Modules
  • Engine Control Units
  • Advanced Driver Assistance Systems (ADAS)

With its compact SC70 package, the SN74LVC1T45QDCKRQ1 is an excellent choice for space-constrained applications, providing reliable logic level translation in a small footprint. Its performance and durability make it an essential component for automotive engineers looking to design systems that require high levels of communication integrity and resilience to environmental factors.
