The TL16C750FNR is a high-performance serial Universal Asynchronous Receiver/Transmitter (UART) interface integrated circuit brought to you by Texas Instruments. This advanced UART is an ideal solution for communications in a wide array of embedded systems, providing enhanced data transmission reliability and speed.

Key Features

• Flexible Baud Rate Generator: The TL16C750FNR can be programmed to generate a wide range of baud rates, allowing it to be used in systems with varying data transmission requirements.
• 64-Byte FIFO Buffers: With its deep FIFO buffers for both transmit and receive, this UART can handle high-speed data streams while minimizing the risk of data loss or overflow.
• Automatic Hardware and Software Flow Control: This feature ensures smooth data flow and prevents buffer overruns by automatically controlling data transmission based on buffer levels.
• Programmable Character Lengths: It supports 5-, 6-, 7-, or 8-bit character lengths, providing flexibility in data format and compatibility with a variety of communication protocols.
• Modem Control: The device includes modem control capability, making it suitable for applications that require remote control and monitoring.
• Low Power Consumption: Designed with power efficiency in mind, the TL16C750FNR is suitable for battery-powered and power-sensitive applications.

Applications

The versatility of the TL16C750FNR allows it to be used in multiple applications such as:

• Industrial control systems
• Point of Sale (POS) terminals
• Networking equipment
• Computer peripherals
• Telecommunications

Technical Specifications

In conclusion, the TL16C750FNR from Texas Instruments is a highly integrated and efficient UART interface IC that meets the needs of complex and demanding communication systems. Its rich set of features and reliable performance make it an excellent choice for designers looking to enhance their serial data communication capabilities.
