The TL431CDBZR from Texas Instruments is a highly precise programmable shunt voltage reference with an output voltage range of 2.495 V to 36 V. It operates with a nominal current range of 1 mA to 100 mA, making it a versatile component for a wide range of applications. This three-terminal adjustable shunt regulator features a low output noise, excellent temperature stability, and low dynamic output impedance, ensuring high reliability and consistent performance.

Encased in a small SOT-23 package, the TL431CDBZR is designed for space-constrained applications. It provides a cost-effective solution for precision voltage regulation, featuring sharp turn-on characteristics and a typical output impedance of 0.2 ohms. This makes it an ideal choice for use in power supplies, battery chargers, and voltage monitoring systems, where tight voltage regulation is crucial.

The TL431CDBZR can be programmed with two external resistors to set the output voltage to a desired value. This flexibility allows designers to tailor the device to meet specific circuit requirements, making it highly adaptable for various electronic designs. Its performance is characterized for operation over the full industrial temperature range of -40°C to +85°C, which ensures that it can maintain its precision under varying environmental conditions.

Key features of the TL431CDBZR include its fast turn-on response, low operational quiescent current, and the ability to sink current up to 100 mA. These features, combined with the device's high stability and low voltage tolerance, make it an excellent choice for use in adjustable voltage or current regulation scenarios, as well as for providing a stable reference voltage in an array of electronic circuits.

Overall, the TL431CDBZR shunt regulator from Texas Instruments is a dependable and flexible component that offers designers a high degree of precision in voltage regulation tasks. Its compact form factor, coupled with its robust feature set, makes it a valuable addition to any electronic system requiring accurate voltage control.
