TLC2274ACD

Part No TLC2274ACD
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 2.25MHZ RRO 14SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 4
Output Type Rail-to-Rail
Slew Rate 3.6 V/μs
Gain Bandwidth Product (GBP) 2.25MHz
Current - Input Bias 1pA
Voltage - Input Offset 300μV
Operating Supply Current 4.8mA
Channel Output Current 50mA
Supply Voltage - Operating 4.4 V to 16 V, ±2.2 V to 8 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Win Source Part Number 054908-TLC2274ACD
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TLC2274ACD CAD Model

Description

Overview of Texas Instruments TLC2274ACD Precision Op Amp

The Texas Instruments TLC2274ACD is a high-precision operational amplifier that combines a wealth of features to address a wide range of applications. This advanced LinCMOS™ operational amplifier has been designed to offer low noise, high speed, and low power consumption, making it an ideal choice for battery-powered systems and high-fidelity audio applications.

Key Features

  • Wide Supply Range: The TLC2274ACD can operate from a supply range of 4.4 V to 16 V, providing designers with flexibility in various circuit configurations and ensuring compatibility with both single and dual power supplies.
  • Low Noise: This op amp boasts a low noise floor, which is critical for precision measurement and high-quality audio applications, ensuring that signal integrity is maintained.
  • High Output Drive Capability: It can drive loads as low as 2 kΩ with minimal distortion, which is particularly useful in driving heavier loads in industrial designs.
  • Low Power Consumption: The device features a typical low supply current of 210 µA per channel, making it suitable for portable and battery-operated equipment.
  • Rail-to-Rail Output Swing: The output can swing very close to the supply rails, maximizing the dynamic range in applications with limited power supply voltages.

Applications

The TLC2274ACD is versatile and can be used in a multitude of applications, including:

  • Active filters
  • Data acquisition systems
  • Audio processing
  • Test equipment
  • Sensor interfaces
  • Professional microphones

Package and Quality

This operational amplifier is offered in a 14-pin SOIC package, which is compact and suitable for space-constrained applications. Texas Instruments ensures high standards of quality and reliability, making the TLC2274ACD a dependable choice for both commercial and industrial applications.

Overall, the Texas Instruments TLC2274ACD operational amplifier is a highly integrated solution that offers precision, low power, and ease of use for engineers looking to optimize their analog circuit designs.
