The TLC272CDRG4 is a high-performance, dual operational amplifier from Texas Instruments, designed to deliver a perfect blend of features that make it suitable for a wide range of applications in the industrial, automotive, and consumer electronics sectors. This precision op-amp is well-regarded for its low power consumption, high input impedance, and the ability to operate from a single power supply over a wide range of voltages.

Key Features

• Low Power Consumption: The TLC272CDRG4 is optimized for low power operations, which makes it ideal for battery-powered devices and energy-efficient systems.
• Wide Supply Range: It operates from a single supply voltage ranging from 4 V to 16 V, or dual supplies of ±2 V to ±8 V, providing flexibility in various circuit configurations.
• High Input Impedance: With a high level of input impedance, it minimizes the impact on signal sources and is suitable for applications requiring a high-input buffer.
• Output Drive Capability: The op-amp can drive loads as low as 2 kΩ with full-rated performance, making it versatile for driving various peripherals.
• Offset Voltage: It features a low input offset voltage, which reduces the need for external calibration and improves overall system accuracy.

Applications

• Signal Conditioning
• Active Filters
• Strain Gauges
• Temperature Sensors
• Analog-to-Digital Converters

The TLC272CDRG4 comes in a compact SOIC-8 package, making it suitable for space-constrained applications. Its operational stability over temperature variations and ability to function at different supply voltages make it a reliable choice for precision amplification tasks. Whether you're designing a sophisticated industrial control system or a simple audio amplifier, the TLC272CDRG4 from Texas Instruments provides the performance and versatility needed to meet your design requirements.

Part Number: TLC272CDRG4
