TPS51206DSQR

Part No TPS51206DSQR
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - Special Purpose
Description DDR Termination Regulator 3.1V to 6.5V 10-Pin WSON EP T/R / IC REG SINK/SOURCE DDR 10SON
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Applications Converter, DDR
Voltage - Input 3.1 V to 6.5 V
Number of Outputs 1
Output Voltage 0.5 V to 0.9 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 10-SON (2x2)
Win Source Part Number 033977-TPS51206DSQR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name TPS51206
Introduction Date May 01, 2010
ECCN EAR99
Country of Origin China, Malaysia, Philippines
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian TPS51206DSQR CAD Model

Description

Product Overview: TPS51206DSQR by Texas Instruments

The TPS51206DSQR is a high-performance, sink/source double data rate (DDR) termination regulator from Texas Instruments (TI), specifically designed to provide a precision voltage regulation for low-power applications. This device is an integral component in memory systems, ensuring stable operation by providing the necessary termination voltage (VTT) and reference voltage (VTTREF) required by DDR2, DDR3, DDR3L, DDR4, LPDDR2, and LPDDR3 memory systems.

With its sink/source capability, the TPS51206DSQR is adept at managing the dynamic power demands of modern memory architectures. It can deliver an output current of up to 2 A, making it suitable for systems with high transient loads. The device operates over a wide input voltage range from 1.1 V to 3.6 V, allowing for flexible design options to accommodate various system requirements.

The TPS51206DSQR comes in a compact, power-saving 10-pin SON package with a small footprint, making it ideal for space-constrained applications. Its low quiescent current contributes to the overall energy efficiency of the system it's integrated into. Additionally, the regulator features a slew rate control that minimizes inrush current during mode transitions, further enhancing its performance in sensitive applications.

TI has equipped the TPS51206DSQR with several protective features for increased reliability and longevity. Overcurrent protection (OCP), thermal shutdown, and under-voltage lockout (UVLO) are all built-in to safeguard the device and the system it is a part of from potential damage due to abnormal operating conditions.

The TPS51206DSQR is a testament to Texas Instruments' commitment to innovation and quality in power management solutions. It is a highly integrated device that offers a mix of efficiency, precision, and robustness, making it an excellent choice for designers looking to optimize the power supply in their DDR memory subsystems.
