Overview of Texas Instruments TPS60400DBV

The TPS60400DBV is a versatile voltage inverter from Texas Instruments, designed to meet the needs of a wide array of applications requiring a stable and efficient power supply. This device is capable of generating a regulated negative voltage from a positive input voltage, making it an ideal component for systems where dual power supplies are necessary.

Key Features

• Input Voltage Range: The TPS60400DBV operates with an input voltage range of 1.6V to 5.5V, which allows it to be used with a variety of power sources, including standard batteries and regulated power supplies.
• Output Voltage: It provides a fixed output voltage that is the negative of the input voltage, ensuring a consistent and reliable power supply for components that require a negative voltage rail.
• High Efficiency: With an efficiency of up to 90%, this device minimizes power loss, making it suitable for battery-powered and portable applications where power conservation is critical.
• Low Noise: The TPS60400DBV features low output voltage ripple, which is essential for sensitive analog and RF circuits that demand a clean power supply.
• Small Package: Housed in a compact SOT-23-5 package, the TPS60400DBV saves valuable board space and is well-suited for space-constrained applications.
• Unregulated Output: The output is unregulated, which allows for a simple design with minimal external components.

Applications

The TPS60400DBV is commonly used in applications such as:

• Portable devices
• Medical equipment
• Operational amplifiers
• Data acquisition systems
• Bipolar analog circuits

Reliability and Support

As with all Texas Instruments products, the TPS60400DBV is manufactured to high standards of quality and reliability. TI provides comprehensive technical support and documentation, including datasheets, reference designs, and application notes, to assist designers in integrating this voltage inverter into their projects.

For engineers and designers looking for a compact, efficient, and easy-to-use negative voltage supply solution, the TPS60400DBV from Texas Instruments offers a perfect blend of performance, size, and simplicity.
