Product Overview: TPS60401DBVT from Texas Instruments

The TPS60401DBVT is a highly efficient, charge pump voltage inverter designed by Texas Instruments. This compact device is perfect for applications that require a negative voltage rail generated from a positive supply voltage. It is commonly utilized in battery-powered equipment, portable devices, and other space-constrained applications where a simple and reliable voltage inversion is needed.

Key Features:

• Input Voltage Range: The TPS60401DBVT operates with an input voltage range from 1.6V to 5.5V, making it versatile for various low-voltage applications.
• Output Current: It can deliver a steady output current of up to 60 mA, which is sufficient for a multitude of low-power devices and circuits.
• High Efficiency: The device features a typical efficiency of 80%, which helps in minimizing power loss and extending battery life in portable applications.
• Low Noise: With its low output voltage ripple, the TPS60401DBVT ensures a clean and stable negative voltage, crucial for sensitive analog and RF circuits.
• Package: It comes in a compact SOT-23-5 package, which not only saves space but also simplifies board layout and design.
• Thermal Shutdown: The built-in thermal shutdown feature protects the device from overheating, thus enhancing its reliability and longevity.

Applications:

• Portable and battery-powered devices
• Medical equipment
• Operational amplifier power supplies
• Data acquisition systems
• Handheld test instruments

The TPS60401DBVT is an ideal choice for designers looking for a simple, efficient, and space-saving solution to generate a negative voltage rail. Its ease of use, coupled with Texas Instruments' reputation for quality and reliability, makes it a go-to component for a wide array of electronic products.
