TPS62162DSGR

Part No TPS62162DSGR
Manufacturer Texas Instruments
Catalog PMIC - Voltage Regulators - DC DC Switching Regulators
Description Conv DC-DC 3V to 17V Synchronous Step Down Single-Out 3.3V 1A 8-Pin WSON EP T/R / IC REG BUCK 3.3V 1A SYNC 8WSON
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Purpose Step-Down
Topology Buck
Output Type Fixed
Number of Outputs 1
Minimum Input Voltage 3V
Maximum Input Voltage 17V
Nominal Output Voltage (Min/Fixed) 3.3V
Output Current 1A
Frequency - Switching 2.25MHz
Synchronous Rectifier Yes
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 8-WSON (2x2)
Win Source Part Number 081709-TPS62162DSGR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name TPS62162
Introduction Date July 01, 2011
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian TPS62162DSGR CAD Model

Description

Overview of the TPS62162DSGR from Texas Instruments

The TPS62162DSGR is a highly efficient synchronous step-down DC/DC converter from the reputable manufacturer Texas Instruments. Designed to cater to the needs of low-power systems, this compact converter integrates advanced features that make it suitable for a wide range of applications, including portable electronics, wireless devices, and industrial control systems.

Key Features

  • Input Voltage Range: The TPS62162DSGR operates with an input voltage range from 3V to 17V, making it versatile for various battery technologies and power supplies.
  • Adjustable Output Voltage: It provides an adjustable output voltage from 0.9V to 6V, which can be set with external resistors, thus allowing flexibility across different loads and applications.
  • High Efficiency: With its synchronous step-down converter design, it achieves high efficiency at light loads and maintains it across a wide load range, thanks to its 2.25MHz fixed switching frequency.
  • Output Current: The device can deliver up to 1A of continuous output current, suitable for a range of mid-power applications.
  • Power Save Mode: To enhance efficiency at light loads, the TPS62162DSGR includes a Power Save Mode that reduces the switching frequency to minimize quiescent current.
  • Thermal and Overcurrent Protection: It is equipped with thermal shutdown and overcurrent protection, safeguarding the device and the system against excessive temperature and load conditions.

Package and Reliability

The TPS62162DSGR is available in a small 2x3mm 8-pin SON package, which is ideal for space-constrained applications. The device is characterized for operation over the free-air temperature range of –40°C to 85°C, ensuring reliable performance under varying environmental conditions.

Applications

With its flexible design and robust feature set, the TPS62162DSGR is well-suited for a myriad of applications, including but not limited to:

  • Portable and battery-powered equipment
  • Wireless power systems
  • Energy harvesting
  • Industrial control circuits
  • Point of load conversions

In summary, the TPS62162DSGR by Texas Instruments is a compact, efficient, and reliable solution for a variety of power conversion needs, offering designers the performance and flexibility required for today's innovative electronics.
