TPS7A9201DSKT

Name: TPS7A9201DSKT
Brand: Texas Instruments
SKU: 848536
Availability: InStock
Rating: 5 (668 reviews)

Part No	TPS7A9201DSKT
Manufacturer	Texas Instruments
Catalog	PMIC - Voltage Regulators - Linear
Description	IC REG LINEAR POS ADJ 2A 10SON / Linear Voltage Regulator IC Positive Adjustable 1 Output 2A 10-SON (2.5x2.5)
Datasheet	TPS7A9201DSKT Datasheet
Sample
ECAD Module

	New List Existing List This product has been added to your List. List Name:

Shipping Information

Shipped from	HK warehouse
Expected Shipping Date	Ship today if order in (HKT)
Supplier Lead-Time	Call for availability
Estimate shipping fee	Enter your destination to get a shipping estimate Estimate Shipping Fee

Pricing & Ordering $0.7857

Quantity

Unit Price

Ext. Price

45+

$1.1310

$50.895

110+

$0.9280

$102.080

170+

$0.8990

$152.830

230+

$0.8700

$200.100

300+

$0.8410

$252.300

400+

$0.7540

$301.600

* The above prices does not include taxes and freight rates, which will be calculated on the order pages.

Availability: 170,987 pieces

MOQ: 45 pcs

Order Increment : 1 pcs

Qty:

*Need More Quantity? *Request a Bulk Quantity Quotation?

Products specifications

Category	Integrated Circuits (ICs) - Power Management (PMIC) - Voltage Regulators - Linear
Mfr	Texas Instruments
Package	Tape & Reel
Product Status	Active
Output Configuration	Positive
Output Type	Adjustable
Number of Regulators	1
Voltage - Input (Max)	6.5V
Voltage - Output (Min/Fixed)	0.8V
Voltage - Output (Max)	5.2V
Voltage Dropout (Max)	0.4V @ 2A
Current - Output	2A
PSRR	40dB (500kHz)
Control Features	Enable, Power Good, Soft Start
Protection Features	Over Current, Over Temperature, Soft Start, Under Voltage Lockout (UVLO)
Temperature Range - Operating	-40°C ~ 125°C (TJ)
Mounting Type	Surface Mount
Package / Case	10-WFDFN Exposed Pad
Supplier Device Package	10-SON (2.5x2.5)
Base Product Number	TPS7A9201
Standard Package	250 pcs
MSL Level	2 (1 Year)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8542.39.0001
Win Source Part Number	848536-TPS7A9201DSKT
Fake Threat In the Open Market	55pct.

Description

Overview of Texas Instruments TPS7A9201DSKT

The TPS7A9201DSKT from Texas Instruments is a highly efficient, low-dropout (LDO) linear voltage regulator designed to deliver outstanding performance in a wide range of applications. This regulator offers a high degree of precision, with an output voltage accuracy of 1%, ensuring reliable operation for sensitive electronic devices.

Key Features

Wide Input Voltage Range: The device is capable of operating with an input voltage range from 1.4V to 6.5V, making it versatile for various power supply configurations.
Adjustable Output Voltage: Users can set the output voltage from 0.8V to 5.0V by using external resistors, providing flexibility for different circuit requirements.
High Output Current: The TPS7A9201DSKT can deliver up to 300mA of continuous output current, which is suitable for powering a broad array of ICs and peripherals.
Low Dropout Voltage: Its low dropout voltage minimizes power loss and improves efficiency, which is especially beneficial in battery-powered applications.
Stable with Low ESR Capacitors: The regulator remains stable with ceramic output capacitors as low as 10μF, reducing the need for larger, bulkier capacitors and saving board space.
Thermal and Overcurrent Protection: Built-in thermal shutdown and current limit features provide protection against excessive temperature and current, enhancing system reliability.
Low Quiescent Current: The device's low quiescent current extends battery life in portable applications, making it an ideal choice for mobile and wearable technology.

Applications

The TPS7A9201DSKT is well-suited for a variety of applications, including but not limited to:

Portable and battery-powered equipment
Wireless communication devices
Power supplies for DSPs, MCUs, and FPGAs
Medical devices and healthcare products
Consumer electronics

In conclusion, the TPS7A9201DSKT from Texas Instruments is a robust, adaptable LDO voltage regulator that provides precise voltage control, high efficiency, and reliable protection features. Its versatility and performance make it an excellent choice for designers looking to optimize power management in their electronic systems.
