UCC14240QDWNRQ1 Texas Instruments – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

UCC14240QDWNRQ1

Part No UCC14240QDWNRQ1
Manufacturer Texas Instruments
Catalog Board Mount AC DC Converters
Description AUTOMOTIVE, 1.5-W, 24-VIN, REGUL
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board MountDC DC Converters
Mfr Texas Instruments
Series UCC14240-Q1
Part Status Active
Type Isolated Module
Number of Outputs 1
Voltage - Input (Min) 21V
Voltage - Input (Max) 27V
Voltage - Output 1 18 ~ 25V
Voltage - Isolation 3 kV
Applications ITE (Commercial), Medical
Features Adjustable Output, Remote On/Off
Operating Temperature -40°C ~ 125°C
Mounting Type Surface Mount
Package / Case 36-BSSOP (0.295", 7.50mm Width)
Size / Dimension 0.51" L x 0.30" W x 0.14" H (12.8mm x 7.5mm x 3.6mm)
Supplier Device Package 36-SSOP
Control Features Enable, Active Low
Standard Number 60950-1; 62368-1
Ultra Librarian 3D Model Ultra Librarian UCC14240QDWNRQ1 CAD Model
