Same model may have multiple batches, images only for reference.
TVR10560KSY Thinking Electronic Industrial Co.,Ltd
Same model may have multiple batches, images only for reference.

TVR10560KSY

Part No TVR10560KSY
Manufacturer Thinking Electronic Industrial Co.,Ltd
Catalog TVS - Varistors, MOVs
Description Varistor 10mm 56V / 56 V 500 A Varistor 1 Circuit Through Hole Disc 10mm
Datasheet
TVR10560KSY Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - Varistors, MOVs
Mfr Thinking Electronics Industrial Co.
Series TVR
Package Bag
Product Status Active
Maximum AC Volts 35 V
Maximum DC Volts 45 V
Varistor Voltage (Min) 50 V
Varistor Voltage (Typ) 56 V
Varistor Voltage (Max) 62 V
Current - Surge 500 A
Energy 7J
Number of Circuits 1
Temperature Range - Operating -40°C ~ 105°C (TA)
Features -
Mounting Type Through Hole
Package / Case Disc 10mm
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
HTSUS 8504.50.4000
Win Source Part Number 1361058-TVR10560KSY
Ultra Librarian 3D Model Ultra Librarian TVR10560KSY CAD Model

Description

The TVR varistor from Thinking Electronics Industrial Co. is a circuit protection component.

  • Application: Transient Voltage Suppressors (TVS) and Varistors, MOVs
  • Temperature Range: -40°C to 105°C
  • Maximum AC Voltage: 35V
  • Maximum DC Voltage: 45V
  • Varistor Voltage: 50V to 62V
  • Surge Current: 500A
  • Energy Rating: 7J
