1SS344 Toshiba Semiconductor and Storage 1SS344 Real Image
Same model may have multiple batches, images only for reference.
1SS344 Toshiba Semiconductor and Storage 1SS344 Real Image
1SS344 Toshiba Semiconductor and Storage 1SS344 Real Image
Same model may have multiple batches, images only for reference.

1SS344

Part No 1SS344
Manufacturer Toshiba Semiconductor and Storage
Catalog Diodes, Rectifiers - Single
Description DIODE (ULTRA HIGH SPEED SWITCHING APPLICATION) / Rectifier Diode Small Signal Schottky 25V 0.5A 20ns 3-Pin S-Mini
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products
Family Diodes,Rectifiers - Single
Manufacturer Toshiba Semiconductor and Storage
Win Source Part Number 150466-1SS344
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name 1SS344
Introduction Date July 15, 1997
ECCN EAR99
Country of Origin Japan
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian 1SS344 CAD Model

Description

1SS344 - Ultra-Compact Diode

The 1SS344 diode is designed for applications requiring ultra-fast switching speeds and compact size, making it a versatile component for modern circuitry.

  • Applications:
    • Digital Circuits
    • High-Speed Data Lines
    • Portable Devices
  • Features:
    • Extremely Fast Switching Speed
    • Low Capacitance
    • Reverse Voltage Rating of 50V
  • Benefits:
    • Improved Signal Integrity
    • Minimal Footprint for Compact Devices
    • Stable Performance Across Temperatures
  • Additional Details:
    • Package Type: SC-70
    • RoHS Compliant
    • Operating Temperature Range: -55°C to +125°C
