TC74HC04AF(EL,F)

Name: TC74HC04AF(EL,F)
Brand: Toshiba Semiconductor and Storage
SKU: 357482
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	TC74HC04AF(EL,F)
Manufacturer	Toshiba Semiconductor and Storage
Catalog	Logic - Gates and Inverters
Description	IC INVERTER HEX 14SOP
Datasheet	TC74HC04AF(EL,F) Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Toshiba Semiconductor and Storage
Packaging	Reel - TR
Status	Active
Logic Type	Inverter
Number of Circuits	6
Number of Inputs	6
Supply Voltage - Operating	2 V to 6 V
Current - Quiescent (Max)	1μA
Current - Output High, Low	5.2mA, 5.2mA
Logic Level - Low	0.5 V to 1.8 V
Logic Level - High	1.5 V to 4.2 V
Max Propagation Delay @ V, Max CL	13ns @ 6V, 50pF
Temperature Range - Operating	-40°C to 85°C
Mounting	SMD (SMT)
Case / Package	14-SOP
Dimension	14-SOIC (0.173", 4.40mm Width)
Win Source Part Number	196945-TC74HC04AF(EL,F)
Popularity	Medium
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian TC74HC04AF(EL,F) CAD Model

Alternative Products

Description

Toshiba Semiconductor and Storage's TC74HC04AF(EL,F) is a reliable inverter logic type integrated circuit designed for surface mount applications.

Circuits: 6 inputs and 6 circuits
Current - Output High, Low: 5.2mA, 5.2mA
Current - Quiescent (max): 1μA
Logic Level - Low: 0.5 V to 1.8 V
Logic Level - High: 1.5 V to 4.2 V
Maximum Propagation Delay: 13ns @ 6V, 50pF
Packaging: Reel - TR
Case/Package: 14-SOP, 0.173", 4.40mm width
Dimension: 14-SOIC
Supply and Demand Status: Balance
Popularity: Medium
