TJ60S06M3L(T6L1,NQ

Name: TJ60S06M3L(T6L1,NQ
Brand: Toshiba Semiconductor and Storage
SKU: 796810
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	TJ60S06M3L(T6L1,NQ
Manufacturer	Toshiba Semiconductor and Storage
Catalog	Transistors - FETs, MOSFETs - RF
Description	MOSFET P-CH 60V 60A DPAK-3 / Trans MOSFET P-CH Si 60V 60A Automotive 3-Pin(2+Tab) DPAK+ T/R
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Toshiba Semiconductor and Storage
Series	U-MOSVI
Packaging	Reel package
Channel Type Type	P
Technology	MOSFET
Drain Source Voltage	60V
Current - Continuous Drain (Id) @ 25°C	60A (Ta)
Drive Voltage (Max Rds On, Min Rds On)	6V, 10V
Vgs(th) (Maximum) @ Id	3V @ 1mA
Gate Charge (Qg) (Maximum) @ Vgs	156nC @ 10V
Input Capacitance (Ciss) (Maximum) @ Vds	7760pF @ 10V
Vgs (Maximum)	+10V, -20V
Power Dissipation (Maximum)	100W (Tc)
Rds On (Maximum) @ Id, Vgs	11.2 mOhm @ 30A, 10V
Operating Temperature Range	175°C (TJ)
Mounting	SMD
Manufacturer Package	DPAK+
Package	TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number	796810-TJ60S06M3L(T6L1,NQ
Popularity	Medium
Supply and Demand Status	Limited
Family Name	TJ60S06M3L
Introduction Date	August 09, 2011
ECCN	EAR99
Country of Origin	Japan
Estimated EOL Date	2029
Ultra Librarian 3D Model	Ultra Librarian TJ60S06M3L(T6L1,NQ CAD Model

Alternative Products

Description

The Toshiba Semiconductor and Storage TJ60S06M3L(T6L1,NQ) is a P-channel MOSFET transistor.

Maximum drain-source voltage: 60V
Continuous drain current: 60A @ 25°C
Low on-resistance: 11.2 mOhm @ 30A and 10V gate-source voltage
Gate charge: 156nC @ 10V gate-source voltage
Input capacitance: 7760pF @ 10V drain-source voltage
Package: TO-252-3, DPak (2 Leads + Tab), SC-63
Series: U-MOSVI
EOL date: 2029
