TLP2362(TPL,E(T)

Name: TLP2362(TPL,E(T)
Brand: Toshiba Semiconductor and Storage
SKU: 370214
Availability: InStock
Rating: 4.85 (246 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	TLP2362(TPL,E(T)
Manufacturer	Toshiba Semiconductor and Storage
Catalog	Optoisolators - Logic Output
Description	Optocoupler Logic-Out Open Collector DC-IN 1-CH 5-Pin SO T/R / Logic Output Optoisolator 10MBd Open Collector 3750Vrms 1 Channel 20kV/μs CMTI 6-SO, 5 Lead
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Isolators
Family	Optoisolators - Logic Output
Manufacturer	Toshiba Semiconductor and Storage
Packaging	Reel(TR)
Number of Channels	1
Inputs - Side 1/Side 2	1/0
Voltage - Isolation	3750Vrms
Common Mode Transient Immunity (Min)	20kV/μs
Input Type	DC
Output Type	Open Collector
Current - Output / Channel	25mA
Data Rate	10MBd
Propagation Delay tpLH / tpHL (Max)	100ns, 100ns
Rise / Fall Time (Typ)	30ns, 30ns
Voltage - Forward (Vf) (Typ)	1.55V
Current - DC Forward (If) (Max)	25mA
Operating Supply Voltage	2.7 V ~ 5.5 V
Operating Temperature Range	-40°C ~ 125°C
Mounting Style	SMD/SMT
Package	6-SOIC (0.179", 4.55mm Width) 5 Leads
Manufacturer Device Package	6-SO, 5 Lead
Win Source Part Number	218098-TLP2362(TPL,E(T)
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	TLP2362
ECCN	EAR99
Country of Origin	Japan, Thailand
Estimated EOL Date	2031
Ultra Librarian 3D Model	Ultra Librarian TLP2362(TPL,E(T) CAD Model

Alternative Products

Description

The TLP2362(TPL,E(T)) is an optoisolator with a logic output manufactured by Toshiba Semiconductor and Storage.

Package: 6-SOIC (0.179", 4.55mm Width) 5 Leads
Mounting: SMD/SMT
Operating Supply Voltage: 2.7 V ~ 5.5 V
Data Rate: 10MBd
Supply and Demand Status: balanced
