TLP2368(TPL,E Real Image TLP2368(TPL,E Real Image
Same model may have multiple batches, images only for reference.
TLP2368(TPL,E Real Image TLP2368(TPL,E Real Image
TLP2368(TPL,E Real Image TLP2368(TPL,E Real Image
Same model may have multiple batches, images only for reference.

TLP2368(TPL,E

Part No TLP2368(TPL,E
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Logic Output
Description OPTOISO 3.75KV OPEN COLL SO6-5 / Logic Output Optoisolator 20MBd Open Collector 3750Vrms 1 Channel 20kV/μs CMTI 6-SO, 5 Lead
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Isolators - Optoisolators - Logic Output Optoisolators
Mfr Toshiba Semiconductor and Storage
Package Tape & Reel
Product Status Active
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Voltage - Isolation 3750Vrms
Common Mode Transient Immunity (Min) 20kV/µs
Input Type DC
Output Type Open Collector
Current - Output / Channel 25 mA
Data Rate 20MBd
Propagation Delay tpLH / tpHL (Max) 60ns, 60ns
Rise / Fall Time (Typ) 30ns, 30ns
Voltage - Forward (Vf) (Typ) 1.55V
Current - DC Forward (If) (Max) 25mA
Voltage - Supply 2.7V ~ 5.5V
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Surface Mount
Package / Case 6-SOIC (0.179", 4.55mm Width), 5 Leads
Supplier Device Package 6-SO, 5 Lead
Base Product Number TLP2368
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.49.8000
Win Source Part Number 845640-TLP2368(TPL,E
Ultra Librarian 3D Model Ultra Librarian TLP2368(TPL,E CAD Model

Description

The TLP2368(TPL,E) is a logic output optoisolator that provides electrical isolation between input and output circuits.

  • Output Type: Open Collector
  • Data Rate: 20MBd
  • Maximum Forward Current: 25mA
  • Forward Voltage: 1.55V
  • Rise Time: 30ns
  • Fall Time: 30ns
  • Channel: Single
  • Voltage Isolation: 3750Vrms
  • Supply Voltage: 2.7V to 5.5V
  • Package: Surface Mount 6-SOIC
  • Leads: 5
