TLP281-4(GB-TP,J,F Toshiba Semiconductor and Storage TLP281-4(GB-TP,J,F real image TLP281-4(GB-TP,J,F label picture TLP281-4(GB-TP,J,F real image11329 TLP281-4(GB-TP,J,F Real Image
Same model may have multiple batches, images only for reference.
TLP281-4(GB-TP,J,F Toshiba Semiconductor and Storage TLP281-4(GB-TP,J,F real image TLP281-4(GB-TP,J,F label picture TLP281-4(GB-TP,J,F real image11329 TLP281-4(GB-TP,J,F Real Image
TLP281-4(GB-TP,J,F Toshiba Semiconductor and Storage TLP281-4(GB-TP,J,F real image TLP281-4(GB-TP,J,F label picture TLP281-4(GB-TP,J,F real image11329 TLP281-4(GB-TP,J,F Real Image
Same model may have multiple batches, images only for reference.

TLP281-4(GB-TP,J,F

Part No TLP281-4(GB-TP,J,F
Manufacturer Toshiba Semiconductor and Storage
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 2.5KV 4CH TRANS 16-SOP
Datasheet
TLP281-4(GB-TP,J,F Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Toshiba Semiconductor and Storage
Packaging Reel - TR
Status Obsolete(EOL)
Number of Channels 4
Isolation Voltage 2500Vrms
Minimum DC Current Transfer Ratio 100% @ 5mA
Maximum DC Current Transfer Ratio 600% @ 5mA
Switching Turn-On and Turn-Off Time 3μs, 3μs
Rise and Fall Time 2μs, 3μs
Input Type DC
Output Type Transistor
Maximum Output Voltage 80V
Channel Output Current 50mA
Forward Voltage 1.15V
Continuous forward current- Max 50mA
Vce Saturation (Max) 400mV
Temperature Range - Operating -55°C to 100°C
Mounting SMD (SMT)
Case / Package 16-SOP
Win Source Part Number 1108895-TLP281-4(GB-TP,J,F
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TLP281-4(GB-TP,J,F CAD Model

Description

The Toshiba Semiconductor and Storage TLP281-4(GB-TP,J,F) is a high-quality optocoupler that is suitable for use in a wide range of electronic devices.

  • Channels: 4
  • Isolation Voltage: 2500Vrms
  • DC Current Transfer Ratio (Min): 100% @ 5mA
  • DC Current Transfer Ratio (Max): 600% @ 5mA
  • Operating Temperature: -55°C to 100°C
  • Mounting Type: Surface Mount (SMT)
  • Packaging: Reel
