The ESD05V36T-4L is a Transient Voltage Suppressor (TVS) diode array manufactured by UN Semiconductor INC. It is designed to protect sensitive electronic components from electrostatic discharge (ESD) and other transient voltage events, particularly in multi-line applications.

Applications

• Protection of data lines in smartphones and tablets
• ESD protection for USB interfaces
• Protection of HDMI ports
• Protection of Ethernet ports
• Protection of SIM card interfaces
• Protection of audio lines

Features

• Low clamping voltage
• Low leakage current
• Fast response time
• Small package size (SOT-23-4L)
• Four channels of ESD protection
• Complies with IEC 61000-4-2 (ESD) standards
• RoHS compliant

Benefits

• Protects multiple sensitive electronic lines from ESD damage, increasing reliability and lifespan.
• Reduces the risk of system failures due to transient voltage events.
• Improves the overall robustness of electronic products.
• The small package size allows for integration in space-constrained applications.
• Meets industry standards for ESD protection.
• Cost-effective solution for multi-line protection.

Additional Details

The ESD05V36T-4L features a standoff voltage of 5V, making it suitable for protecting 5V logic circuits. Its low clamping voltage ensures that the voltage seen by the protected components remains within safe limits during an ESD event. The device is available in a small SOT-23-4L package. It provides protection for four individual I/O lines. The specific clamping voltage during an ESD event depends on the specific ESD pulse. It is designed to safely dissipate ESD strikes that would otherwise damage downstream components. The part is lead-free and complies with environmental regulations.
