ESD48V32D-C

Part No ESD48V32D-C
Manufacturer UN Semiconducctor INC
Catalog END - OF - LIFE
Description Transient Voltage Suppressors for ESD Protection
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer UN Semiconducctor INC
Win Source Part Number 1172633-ESD48V32D-C
Manufacturer Homepage www.unsemi.com.tw
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ESD48V32D-C CAD Model

Description

The ESD48V32D-C is an Electrostatic Discharge (ESD) protection diode from UN Semiconductor INC, designed to safeguard sensitive electronic components from damage caused by ESD events. ESD can occur during manufacturing, handling, or the operation of electronic equipment. This diode is categorized as END-OF-LIFE.

Applications

  • Protection of industrial control systems
  • Protection of automotive electronics
  • Protection of telecom equipment
  • Protection of power supplies
  • Protection of high-voltage interfaces

Features

  • High standoff voltage (48V)
  • Low clamping voltage
  • Fast response time
  • Small package size
  • High surge current capability

Benefits

  • Protects sensitive components from ESD damage
  • Increases system reliability
  • Reduces warranty costs
  • Extends product lifespan
  • Easy to integrate into existing designs

Additional Details

The ESD48V32D-C is typically available in a small surface-mount package. It provides a standoff voltage of 48V, making it suitable for protecting higher voltage circuits. Its low clamping voltage ensures that downstream components are not exposed to excessive voltage during an ESD event. The device is designed to meet industry-standard ESD immunity requirements, such as IEC 61000-4-2. This is a transient voltage suppression (TVS) diode. It protects against contact discharge events.

As this product is designated END-OF-LIFE, it is recommended to consult with UN Semiconductor INC or its distributors for suitable replacement options for new or ongoing projects.
