Same model may have multiple batches, images only for reference.
H2U34W1H1Z0400 Real Image
Same model may have multiple batches, images only for reference.

H2U34W1H1Z0400

Part No H2U34W1H1Z0400
Manufacturer Unictron Technologies Corporation
Catalog RF Antennas
Description WIFI/BT 2400-2500MHZ TELA CERAMI / WiFi/Bluetooth Ceramic Chip Antenna
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Unictron Technologies Corporation
Packaging Reel
RF Family/Standard 802.15.4, Bluetooth, General ISM, WiFi
Frequency Group UHF (2GHz ~ 3GHz)
Frequency (Center/Band) 2.45GHz
Frequency Range 2.4GHz ~ 2.5GHz
Antenna Type Chip
Number of Bands 1
VSWR 2
Gain 1.5dBi
Power - Max 2W
Termination Solder
Mounting Style SMD
Height (Maximum) 0.020" (0.50mm)
Applications 802.11b/g/n, Bluetooth, ISM, Wi-Fi, Zigbee
Manufacturer Pack Quantity 5,000
MSL Level 2A (4 Weeks)
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 806286-H2U34W1H1Z0400
Ultra Librarian 3D Model Ultra Librarian H2U34W1H1Z0400 CAD Model

Description

The H2U34W1H1Z0400 is a chip antenna manufactured by Unictron Technologies Corporation.

  • Frequency Range: 2.4GHz to 2.5GHz
  • Applications: 802.11b/g/n, Bluetooth, ISM, Wi-Fi, Zigbee
  • Maximum Power: 2W
  • Gain: 1.5dBi
  • VSWR: 2
  • UHF Frequency Group: Yes
  • Packaging: Reel (5000 units)
  • Popularity: Medium
