The CHX2092A-99F/00 is a GaAs monolithic microwave integrated circuit (MMIC) designed by United Monolithic Semiconductors (UMS). It is a high-performance, low-noise amplifier suitable for a variety of applications within the microwave frequency range. Its END-OF-LIFE status suggests it is no longer in active production, making knowledge of its specifications critical for legacy systems.

Applications

• Satellite communication systems
• Radar receivers
• Electronic warfare systems
• Test and measurement equipment
• Microwave radio links

Features

• High gain
• Low noise figure
• Wide bandwidth
• Good input and output matching
• GaAs MMIC technology
• Compact size

Benefits

• Enhances receiver sensitivity
• Improves signal-to-noise ratio
• Provides high linearity
• Simplifies system design
• Reduces overall system cost
• Enables compact system solutions

Additional Details

The CHX2092A-99F/00 typically operates in the Ku-band frequency range. Its GaAs MMIC design ensures high performance and reliability. The amplifier is generally supplied in die form, requiring careful handling and assembly. Specific performance parameters, such as gain, noise figure, and output power, vary with frequency and bias conditions. Detailed specifications are usually available in the manufacturer's datasheet.

Given its END-OF-LIFE status, engineers should consider potential replacement components for new designs, while those maintaining existing systems may need to source remaining stock carefully.
