Same model may have multiple batches, images only for reference.
110CNQ045ASM Real Image
Same model may have multiple batches, images only for reference.

110CNQ045ASM

Part No 110CNQ045ASM
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description SCHOTTKY RECTIFIER New GenIII D-61 Package | DIODE ARRAY SCHOTTKY 45V D618SM
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay Semiconductor Diodes Division
Packaging Bulk
Status Obsolete
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Maximum) 45V
Current - Average Rectified (Io) (per Diode) 55A
Voltage - Forward (Vf) (Maximum) at If 540mV at 55A
Speed Fast Recovery = 200mA (Io)
Current - Reverse Leakage at Vr 3mA at 45V
Operating Temperature - Junction -55°C ~ 150°C
Mounting Style Through Hole
Manufacturer Package D-61-8-SM
Supplier Device Package D-61-8-SM
Family Part Number 110CNQ045
Manufacturer Pack Quantity 400
MSL Level 1 (Unlimited)
Win Source Part Number 721298-110CNQ045ASM
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 110CNQ045ASM CAD Model

Description

The 110CNQ045ASM is a fast recovery Schottky diode from Vishay Semiconductor Diodes Division.

  • Maximum Reverse Voltage: 45V
  • Forward Voltage: 540mV @ 55A
  • Current Rating: 55A
  • Applications: Rectification, power supplies, and DC-DC converters
  • Status: Obsolete
  • Popularity: Medium
