113CNQ100ASM Real Image
Same model may have multiple batches, images only for reference.

113CNQ100ASM

Part No 113CNQ100ASM
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description DIODE ARRAY SCHOTTKY 100V D618SM  /  Diode Array 1 Pair Common Cathode Schottky 100 V 55A Through Hole D-61-8-SM
Datasheet
113CNQ100ASM Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Diodes - Rectifiers - Arrays
Mfr Vishay General Semiconductor - Diodes Division
Package Bulk
Product Status Obsolete
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 100 V
Current - Average Rectified (Io) (per Diode) 55A
Voltage - Forward (Vf) (Max) @ If 810 mV @ 55 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 1 mA @ 100 V
Operating Temperature - Junction -55°C ~ 175°C
Mounting Type Through Hole
Package / Case D-61-8-SM
Supplier Device Package D-61-8-SM
Base Product Number 113CNQ100
RoHS Status RoHS non-compliant
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Other Names *113CNQ100ASM,VS-113CNQ100ASM,VS-113CNQ100ASM-ND,VS113CNQ100ASM,VS113CNQ100ASM-ND
Standard Package 400
Win Source Part Number 1182069-113CNQ100ASM
Ultra Librarian 3D Model Ultra Librarian 113CNQ100ASM CAD Model

Description

The Vishay General Semiconductor - Diodes Division 113CNQ100 series of rectifier diodes includes the 113CNQ100ASM diode.

  • Type: Schottky
  • Maximum Voltage Rating: 100 V
  • Current Rating: 55 A
  • Forward Voltage: 810 mV @ 55 A
  • Reverse Leakage Current: 1 mA @ 100 V
  • Diode Configuration: 1 Pair Common Cathode
  • Mounting Type: Through Hole
