60EPU06PBF Real Image 60EPU06PBF real image308 60EPU06PBF real image309
Same model may have multiple batches, images only for reference.
60EPU06PBF Real Image 60EPU06PBF real image308 60EPU06PBF real image309
60EPU06PBF Real Image 60EPU06PBF real image308 60EPU06PBF real image309
Same model may have multiple batches, images only for reference.

60EPU06PBF

Part No 60EPU06PBF
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 600V 60A TO247AC
Datasheet
60EPU06PBF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Tube/Rail
Status Active
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 600V
Current - Average Rectified (Io) 60A
Voltage - Forward (Vf) (Max) @ If 1.68V @ 60A
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 81ns
Current - Reverse Leakage @ Vr 50μA @ 600V
Mounting Through Hole
Case / Package TO-247AC Modified
Operating Temperature - Junction -55°C to 175°C
Win Source Part Number 197891-60EPU06PBF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian 60EPU06PBF CAD Model

Description

60EPU06PBF Diode

The 60EPU06PBF diode is tailored for high voltage rectification and power conversion tasks. It features excellent thermal performance and rugged construction to withstand the rigors of modern electronic circuits.

  • Features and Benefits:
    • High thermal performance for robust operation
    • Rugged construction for enhanced durability
    • Efficient at high voltage applications
  • Applications/Projects:
    • Battery charger circuits
    • Power inverters
    • Renewable energy systems
  • Additional Details:
    • Peak reverse voltage: 600V
    • Average forward current: 60A
    • Package: TO-220AC
