DG412DY-T1-E3 Real Image DG412DY-T1-E3 real image3275 DG412DY-T1-E3 Real Image
Same model may have multiple batches, images only for reference.
DG412DY-T1-E3 Real Image DG412DY-T1-E3 real image3275 DG412DY-T1-E3 Real Image
DG412DY-T1-E3 Real Image DG412DY-T1-E3 real image3275 DG412DY-T1-E3 Real Image
Same model may have multiple batches, images only for reference.

DG412DY-T1-E3

Part No DG412DY-T1-E3
Manufacturer Vishay
Catalog Interface - Analog Switches, Multiplexers, Demultiplexers
Description IC SWITCH QUAD SPST 16-SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Vishay
Packaging Reel - TR
Status Active
Switch Circuit SPST - NO
Number of Circuits 4
Max On Resistance 35 Ohm
Single Supply Voltage (V+) 5 V to 44 V
Dual Supply Voltage(V±) ±5 V to 20 V
Max Switch Time (Ton,Toff) 175ns, 145ns
Charge Injection 5pC
Channel Capacitance(CS off, CD off) 9pF, 9pF
Max Leakage Current (IS off) 250pA
Crosstalk -85dB @ 1MHz
Temperature Range - Operating -40°C to 85°C (TA)
Case / Package 16-SOIC
Win Source Part Number 117277-DG412DY-T1-E3
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian DG412DY-T1-E3 CAD Model

Alternative Products

Alternative Product Part Number Manufacturer Package Country Similarity
DG412AK ADI Ceramic Dual-In-Line, Narrow (0.3in) United States Functional Equivalent
DG412DY-T1 VISHAY SOIC-16(154mil) United States PIN-TO-PIN
DG442AK/883B ADI United States Functional Equivalent
DG442CY+ ADI SOIC-16(150mil) United States Functional Equivalent
DG442CY+T ADI SOIC-16(150mil) United States Functional Equivalent
MAX313C/D ADI 0-CHIP-N/A United States Functional Equivalent
MAX313CSE+ ADI NSOIC United States Functional Equivalent
MAX313MJE ADI Ceramic Dual-In-Line, Narrow (0.3in) United States Functional Equivalent
MAX327ESE+T ADI SOIC-16(150mil) United States Functional Equivalent
MAX4602EWE+ ADI Small-Outline IC, Wide (0.3in) United States Functional Equivalent

Description

Description

The DG412DY-T1-E3 is a high-performance, monolithic CMOS analog switch designed for precision applications. It offers fast switching times and low on-resistance, making it ideal for a variety of electronic applications.

Features and Benefits

  • Low on-resistance for minimal signal loss
  • Fast switching times enhance efficiency
  • Wide power supply range supports diverse applications

Applications

  • Data acquisition systems
  • Analog signal routing
  • Sample-and-hold circuits
  • Communication systems

Additional Details

The DG412DY-T1-E3 ensures reliability and performance through advanced CMOS technology, offering precise analog signal switching with minimal distortion. The robust design simplifies the integration into complex systems, supporting seamless operation in a wide range of environments.
