The Vishay IL4116-X007 is an electronic component that is designed for isolators.

• Output Type: Triac
• Forward Voltage: 1.3V
• Voltage Off-State: 600V
• Maximum Current On-State (It (RMS)): 300mA
• Channel: One
• Isolation Voltage: 5300Vrms
• Current Hold (Ih): 200μA
• Zero-Crossing Circuit: Yes
• Static dV/dt (Min): 10kV/μs
• Current LED Trigger (Ift) (Max): 1.3mA
• Turn-On Time: 35μs
• Continuous Forward Current-Max: 60mA
• Package: Tube/Rail
• Approvals: BSI, CSA, cUR, FIMKO, and UR
• Mounting: SMD (SMT)
• Operating Temperature Range: Between -55°C to 100°C

The device is packaged in tube/rail, and the approvals are BSI, CSA, cUR, FIMKO, and UR. The mounting is SMD (SMT), and the device has a popularity of medium. The operating temperature range is between -55°C to 100°C.
