IRFP240 Real Image IRFP240 Real Image
Same model may have multiple batches, images only for reference.
IRFP240 Real Image IRFP240 Real Image
IRFP240 Real Image IRFP240 Real Image
Same model may have multiple batches, images only for reference.

IRFP240

Part No IRFP240
Manufacturer Vishay
Catalog Transistors - FETs, MOSFETs - RF
Description MOSFET N-CH 200V 20A TO-247AC
Datasheet
IRFP240 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay
Packaging Tube/Rail
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 200V
Continuous Drain Current at 25°C 20A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Gate-Source Threshold Voltage 4V @ 250μA
Max Gate Charge 70nC @ 10V
Max Input Capacitance 1300pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 150W (Tc)
Maximum Rds On at Id,Vgs 180 mOhm @ 12A, 10V
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting Through Hole
Case / Package TO-247-3
Dimension TO-247-3
Win Source Part Number 090797-IRFP240
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian IRFP240 CAD Model

Description

The IRFP240 is an N-channel MOSFET manufactured by Vishay.

  • Case/Package: TO-247-3
  • Operating Temperature Range: -55°C to 150°C
  • Maximum Power Dissipation: 150W (Tc)
  • Continuous Drain Current at 25°C: 20A (Tc)
  • Maximum Gate Charge: 70nC @ 10V
  • Maximum Input Capacitance: 1300pF @ 25V
  • Popularity: High
  • Supply and Demand: Limited
