Same model may have multiple batches, images only for reference.
SB060-E3/54 Real Image
Same model may have multiple batches, images only for reference.

SB060-E3/54

Part No SB060-E3/54
Manufacturer Vishay
Catalog Diodes, Rectifiers - Single
Datasheet
SB060-E3/54 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products>Diodes - Rectifiers - Single
Mfr Vishay General Semiconductor - Diodes Division
Package Tape & Reel (TR)
Product Status Obsolete
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 60 V
Current - Average Rectified (Io) 600mA
Voltage - Forward (Vf) (Max) @ If 700 mV @ 600 mA
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 500 µA @ 60 V
Mounting Type Through Hole
Package / Case MPG06, Axial
Supplier Device Package MPG06
Operating Temperature - Junction -65°C ~ 150°C
Base Product Number SB060
Standard Package 5,500
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 1281589-SB060-E3/54
Ultra Librarian 3D Model Ultra Librarian SB060-E3/54 CAD Model

Description

The SB060-E3/54 is a Schottky diode with a maximum reverse voltage of 60 V and an average rectified current of 600mA.

  • Maximum Reverse Voltage: 60 V
  • Average Rectified Current: 600mA
  • Voltage Forward: 700 mV @ 600 mA
  • Current Reverse Leakage: 500 µA @ 60 V
  • Mounting Type: Through Hole
  • Package/Case: MPG06, Axial
  • Operating Temperature Range: -65°C to 150°C
  • Recovery Speed: =< 500ns, > 200mA (Io)
  • Status: Obsolete
  • Standard Package: 5,500
